Async, Non-Blocking and Blocking I/O

https://unsplash.com/photos/uj3hvdfQujI

Table of Contents

Process, Thread and Memory Management

Modern computers run programs simultaneously. You can listen to Spotify, browser internet in Chrome and play video games at the same time. Spotify doesn't stop when you play a video game, video games don't stop when you receive messages in telegram. Are those programs run in parallel? Let's try to figure it out.

  • Every program is executed in one or multiple processes.
  • Each process consists of one or multiple threads.
  • Each CPU core can run only one process at a time.

Computer runs only N programs in parallel, where N is a number of CPU cores.

Let's suppose we have one core CPU computer. Even this computer can run multiple programs simultaneously, Spotify doesn't stop when you copy 10GB video. How is it possible?

The audio player doesn't stop, it pauses. It pauses very short to give control to another program. Another program makes progress and pauses again. Pauses are too short to be noticeable. It is called Multitasking.

Multitasking -- illusion that programs run in parallel.

O/S level component that defines the way processes use CPU is called Scheduler. It defines methods of assigning resources to processes.

When Scheduler replaces the executing process, it needs to save the process's state, load state of the next process and resume it. The process works for some time and algorithms repeats. Saving and restoring process state is called Context switching.

Process

  • instance of program
  • has one or many threads
  • contains code and activity

Thread

  • smallest primitive managed by a scheduler
  • part of the process

Scheduler

  • assigns work to resources that complete the work
  • work may be virtual computation elements such as threads, processes, data flows
  • which scheduled onto hardware resources such as CPU, GPU,

Multitasking

  • method of sharing processor and system resources
  • allows a processor to switch between tasks
  • switches performed on I/O or hardware interrupts or time quotas

Time-Sharing

  • most common form of multitasking
  • illusion that applications run in parallel

Process - Representation

  • machine code of the executable programm
  • memory
    • executable code
    • input-output data
    • call stack
    • heap
  • system descriptors (files, handlers, sinks)
  • security attributes
  • processor state (context), registers, addresses.

Security

  • OS keeps processes separate
  • processes don't interfere with each other
  • OS allocates the resources processes need

Process vs Thread

  • processes are independent - threads are part of process
  • process carry all system information - threads are sharing process state, memory and resources
  • processes have separate address space, whereas threads share their address space
  • processes interact only through the system provided inter-process communication mechanisms
  • processes context switching is expensive - threads context switching is cheaper

Context switching

When it is time to some CPU time to another process, O/S saves the state of currently running process, loads state of another process and resumes it on CPU. This is called Context Switching.

The scheduler works with both Processes and Threads. Performing process context switch is more expensive than performing a thread context switch. Threads share memory and resources with the parent process. Thread switch requires fewer changes in the current state.

Async, Non-Blocking and Blocking I/O

Programs read and write data. The type of I/O model determines how efficiently the program is using CPU. For example, Apache Web Server is using Blocking I/O. When you request a web page, it will read data from the filesystem or network. The process will be blocked until the operation is complete.

Let's imagine that we have 10000 simultaneous users. Users request different pages. While one process is blocked, all 10000 will have to wait for it to complete. That is not usable.

That's why Apache Web Server forks new process per new open connection. When one process blocks, it doesn't affect other processes. It works fine, but there is one problem with this approach.

  • 100000 processes cost a lot of memory
  • 100000 processes waste a lot of time for context switching

Next example is Nginx webserver. It uses async I/O model. It is single-threaded. It can handle much more open connections and requests per second using fewer resources.

Basic idea is that it has one worker thread. Each I/O read/write doesn't block worker thread. Instead, those calls only start operation and execution continues. As soon as the result will be ready it will be added to the event queue. Worker thread takes events from the event queue and handles them. This way the server doesn't waste memory and CPU.

I/O forms:

  • Blocking
  • Non-blocking
  • Asynchorous

Blocking I/O

  • io operation blocks execution context(thread or process)
# Open socket, read data from socket, print it.
socket = network.open()
data = socket.read() # Execution blocked untill read operation is complete
print(data)

Non-Blocking I/O --- Polling

  • I/O operations don't block execution
  • result of the operation has to be polled
  • pooling eats CPU cycles
# Open socket, wait until the socket is ready, read data and print it.
socket = network.open()
ready = False
while not ready: # Execution is not blocked by the system, but blocked by the loop.
  ready = network.poll(socket, 'input')
data = socket.read() # Read immidiatly returns result.
print(data)

Async I/O --- Callback

  • I/O operations don't block execution
  • Completion of the operations notifies execution
# Open socket, create callback, initiate read and pass callback.
loop = create_event_loop()
socket = network.open(loop)
def handler(err, data): # callback function
  if err:
    return print('Error reading data, {}'.format(err))
  print(data)
socket.read(handler)
loop.run()

Event loop. Libuv. Node.js. Twisted

https://unsplash.com/photos/0a5VbkqqFFE

Event Table

  • each async operation added to the event table
  • maps events to handler functions
  • doesn't execute handlers

Event queue

  • list of events ready for handling

Event loop

  • constantly running process spinning loop
  • each loop iteration handles an event from the event queue
  • runs event handler from the event table
# Pseudo code illustrating work of event loop
while True:
  event = event_queue.get()
  if event:
    handler = event_table[event.id]
    handler(event)

Libuv

Cross-Platform library focusing on Async I/O. Developed primarily in C for Node.js. Nowadays widely used outside of initial scope.

  • built around the event loop
  • event loop tied to a single thread

Features

  • cross-platform asynchronous I/O library
  • abstractions on top of epoll, kqueue, IOCP, event ports
  • async TCP / UDP
  • async DNS
  • async fs operations
  • child processes
  • thread pool

Network I/O

I/O performed on non-blocking sockets:

  • epoll on Linux
  • kqueue on OSX and other BSDs
  • event ports on SunOS
  • IOCP on Windows

Thread Pool

Not all operations are async in libuv. Because of lack of O/S level API for file I/O, libuv uses thread pool under the hood for next operations:

  • File system operations
  • DNS functions
  • User specified code

Node.js

Node is an open-source platform that allowed JavaScript to move outside of the browser. It was created by Ryal Dahl as a result of his frustration with Apache HTTP server in 2009. Apache HTTP server uses process per connection model. For each open connection, the server spawns one more child process. This model is very limited if you want to handle a huge number of concurrent connections.

Node.js consists of two parts

  • Google V8 JavaScript engine
  • Libuv library for managing I/O

JavaScript is one of the best languages for async programming model, as it was always async, and the whole ecosystem of libraries already supported the async model.

Python

Asyncio

Library to write concurrent code using async/await syntax. Foundation for writing high-performance I/O heavy applications in python.

Asyncio is implemented around python select module. Select module provides access to select, poll, devpoll, epoll, kqueue.

Uvloop is a python wrapper around libuv, which can be used as a replacement for select module. This can make the asyncio module faster, more about this in the article uvloop: Blazing fast Python networking, by Yury Selivanov

Asyncio - Hello World

import asyncio
async def main():
    print('Hello ...')
    await asyncio.sleep(1)
    print('... World!')
asyncio.run(main())

Asyncio - Quering postgresql

import asyncio
import asyncpg
async def run():
    conn = await asyncpg.connect(...)
    values = await conn.fetch('''SELECT * FROM cats''')
    await conn.close()
    print(values)
asyncio(run())

Sanic (Async Flask)

Sanic - Amazing library heavily inspired by flask and built around asyncio.

from sanic import Sanic
from sanic.response import json
from asyncpg import create_pool
## Init Sanic
app = Sanic(__name__)
## Database management
@app.listener('before_server_start')
async def connect_to_database(app, loop):
    pool = await create_pool(user='postgres', password='postgres',
                             database='postgres', host='127.0.0.1',
                             loop=loop)
    app.config['pool'] = pool
@app.listener('after_server_stop')
async def close_connection(app, loop):
    pool = app.config['pool']
    async with pool.acquire() as conn:
        await conn.close()
## Database queries
async def get_tweets(pool):
    sql = '''
        SELECT id, text FROM tweets;
    '''
    async with pool.acquire() as conn:
        rows = await conn.fetch(sql)
        return rows
async def get_tweet(pool, id):
    sql = '''
        SELECT id, text FROM tweets
        WHERE id = $1;
    '''
    async with pool.acquire() as conn:
        rows = await conn.fetch(sql, id)
        return rows
## Http handlers
@app.route("/api/tweets/<id>")
async def handler_request(req, id):
    pool = req.app.config['pool']
    tweet = await get_tweet(pool, int(id))
    return json(tweet)
@app.route("/api/tweets")
async def handler_request(req):
    pool = req.app.config['pool']
    tweets = await get_tweets(pool)
    return json(tweets)
if __name__ == "__main__":
    app.run(host="0.0.0.0", port=8000)
